Features:
- LCD digital control of speed and temperature.
- Maintenance free brushless DC motor.
- RS232 interface enables data preservation, transmission and control by a PC.
- Speed setting range from 0-1500rpm.
- RS232 interface provides PC control and data transmission.
- Ceramic workplate with max. temperature of 340°C.
- Various optional accessories make it suitable for many applications.
- “Hot” safety indication on LED when the plate temperature is above 50°C.
- PT1000 external temperature sensor for precise temperature control at of ±0.2°C.
Specification:
| Workplate dimension | φ135mm (5 inch) |
| Workplate material | Stainless steel cover with ceramic |
| Motor type | Brushless DC motor |
| Motor rating input | 18W |
| Motor rating output | 10W |
| Power | 550W |
| Heating output | 500W |
| Voltage | 100-120/200-240V 50/60Hz |
| Stirring positions | 1 |
| Max. stirring volume [H2O] | 20L |
| Max. magnetic bar [length] | 80mm |
| Speed range | 100-1500rpm
resolution±1rpm |
| Speed display | LCD |
| Temperature display | LCD |
| Heating temperature range | Room Temp.-340°C,
increment 1°C |
| Temperature control accuracy | ±1°C (<100°C)
±1% (>100°C) |
| Overheating protection | 360℃ |
| Temperature display resolution | ±0.1°C |
| External temperature sensor | PT1000 (accuracy ±0.2) |
| “Hot” satety indication | 50℃ |
| Timer function | – |
| Data interface | RS232 |
| Protection class | IP42 |
| Dimension [W*D*H] | 160*280*85mm |
| Weight | 2.8kg |
| Permissible ambient temperature and humidity | 5-40C, 80%RH |
