Features:
- Brushless DC motor drive, low noise and maintenance free.
- Stainless steel head restraints, more durable.
- Stirrer with digital type has three kinds of rotation mode as positive rotation, inversion, reciprocal and mutual conversion.
Specification:
| Model | PH-II-6 | PH-II-6C | PH-II-7C | |
| Function | Max. Volume(L) | 20 | 20 | 40 |
| digital | – | LCD | LCD | |
| Speed(r.p.m) | 100～2500 | 100～2500 | 100～2500 | |
| Working time | Continous | |||
| Minimum revolution (r.p.m) | 100 | 100 | 100 | |
| Structure | Exterior | Plastic shell | ||
| Driving mode | Motor | |||
| Motor power (kW) | 0.06 | 0.06 | 0.08 | |
| Controller | Continuous operation | Yes | ||
| Setting mode | Scale | Digital | Digital | |
| Speed display mode | Scale | Digital | Digital | |
| Timer | No | Yes | Yes | |
| Operation function | Yes | Yes | Yes | |
| Specification | Exterior size (W*L*H)(mm) | 115*95*240 | ||
| Packing size (W*L*H)(mm) | 400*250*210 | |||
| Plate size ( mm ) | 200*300 | |||
| Plate load | 50KG | |||
| Power supply (50/60Hz) Current rating | 100～240V | |||
| NW/GW (kg） | 5/6 | 6/7 | 7/8 | |
